Arnold Series Cable Crossover Pin Loaded Machine | Black Finish

The Cable Crossover from the Arnold Series of strength machines is a heavy duty commercial machine that has been built to last.


     Assembled dimensions
    Weight 380kg
    Length 1650mm
    Width 1000mm
    Height 2400mm


    Gross shipping weight 550kg at 2.05m3

    Specifications:

    Code: VER-ARN-025
    Weight 380kg
    Warranty

    5 YEARS: Rack welding parts, adjustable dish, and weight stacks.

    2 YEARS: Bearing, pulley, guide rod.

    1 YEAR: Belt, linear bearing, bush and pull pin.

    6 MONTHS: Steel wire rope, end cap, sliding sleeve, cushion and back pad, foam, and other accessories.

    ALL OTHER PARTS not mentioned, one year from the date of purchase to the original purchaser.

    Frame

    Heavy duty 100mm x 50mm x 3mm thick oval steel frames with a combination of 50mm round tubing.

    Cables

    3/16" USA-Made/Certified EXERFLEX PRO high performance cable.

    4-1/2” and 3-1/2” diameter fiberglass reinforced nylon pulleys with sealed bearings enclosed in protective steel covers.

    Padding

    High density EMR Urethane foam padding with double-stitched upholstery (black) secured to 3/4” plywood backing.

    Finish

    Powder coat finish

    Weight Stack

    90kg steel weight stacks. Steel weight stack enclosures with decorative built-in storage compartment cover

    Cable Ratio 4:1
    Other Specs

    Sealed 50mm roller bearings and 25mm diameter solid steel axle encased in machined housing on all primary pivot points.

    20mm precision ground, hard chrome finish, solid steel guide rods.

    Thermoplastic rubber handgrips secured with aluminium end caps for durability and improved feel.

    Protective rubber stabilizer feet with anchoring holes provided on all machines.

    Functional Trainer Cable Crossover - Arnold Series

    $5,699 Regular price $7,999 SAVE $2,300
